Fiber Laser Rust Removal Machine

Fiber Laser Rust Removal Machine

Easy to operate.
Energy saving.
Low running cost.

Description

Fiber Laser Rust Removal Machine

Product Description

This fiber laser rust removal machine is small and portable, the cleaning process is very simple and fast, the design is compact, and the weight of the whole machine is only 10kg.

With a backpack style design, you can carry it on your back to clean places that other large equipment cannot reach, such as outdoor work at heights, corner cleaning, etc.

Product Overview

Product Features

1. Fiber laser rust removal machine is an air-cooled pulsed laser system for high performance, industrial grade, fast, precise and incredibly efficient laser cleaning.

2. The ultra-compact enclosure is designed as a professional-grade laser cleaning and finishing system for small areas that require delicate cleaning, paint stripping, and other finishing operations.

3. Special metal housings are interchangeable to meet customer needs and can be easily installed on any production line or robotic arm.

product part

Product Parameters

Model

RL-C100 mini

RL-C50 mini

Laser source

100w pulsed fiber laser

50w pulsed fiber laser

Laser Power

100W

50W

Fiber cable length

3 M

3 M

Laser Wavelength

1064nm

1064nm

Pulse Energy

1mJ

0.8 mJ

Pulse frequency

20-400KHz

45-170KHz

Cooling

Air cooling

Air cooling

Dimension

38*15.2*28cm

31.8*28.5*12.7cm

Weight

12.5Kg

8Kg

Beam width

10-100mm

10-100mm

Optional

Manual

Manual

Temperature

5-40 ℃

5-40 ℃

Voltage

Single Phase

AC 220V,50/60HZ

Single Phase

AC 220V, 50/60HZ

Product Video

Products Application

This fiber laser rust removal machine is mainly used for laser graffiti clean, weld cleaning and metal primer removal.

Samples

Product Packaging

About our fiber laser rust removal machine packing and shipping, firstly our workers will make sure your fiber laser cleaning machine is well tested and clean before packing, then add stretch film and spare parts for the whole machine for sweet protection, and finally we will make export standard strong carton case package according to your needs.

packaging shipping
