20W High Speed MOPA Fiber Laser Marking For Metal & Plastic
High photoelectric conversion efficiency,
simple operation, compact structure,
support for harsh working environment, no consumables.
Description
20W High Speed MOPA Fiber Laser Marking For Metal & Plastic
Product Features
1. High photoelectric conversion efficiency, simple operation, compact structure, support for harsh working environment, no consumables.
2. Modular design, separate laser generator and elevator, more flexible, can mark larger areas and complex surfaces. The interior is air-cooled, takes up little space and is easy to install.
3. The fiber laser generator is highly integrated, with superior laser beam and uniform power density. The output laser power is stable. This design greatly improves the anti-reflective ability of the machine through the optical isolator and can mark most highly reflective materials (such as aluminum, copper, gold and silver) without shadows or virtual aperture.
4. Adopt advanced high-speed digital scanning galvanometer, fast speed, no deviation, small size, good stability, and the performance reaches the international advanced level.
5. With the ezcad embedded operating system, the performance is ahead of its domestic counterparts, and the good touch interface and powerful control system can meet the needs of most of the industry application process in the market.
Product Details
Parameters
High speed Mopa fiber laser marking for metal & plastic | |
Laser Type | Fiber laser |
Laser Power | 20W 30W 50W 70W 100W |
Model | RL-20W RL-30W RL-50W RL-70W RL-100W |
Laser Wavelength | 1064nm |
Marking Area | 75*75mm 110*110mm 150mm*150mm |
| 175mm*175mm 200*200mm 300*300mm | |
Marking Depth | ≤1.2mm |
Marking Speed | 10000mm/s |
Minimum Line Width | 0.012mm |
Minimum Character | 0.15mm |
Repeated Precision | ±0.003mm |
Life-span of Fiber Laser Module | 100000hours |
Beam Quality | M2<1.5 |
Focus Spot Diameter | <0.01mm |
Output Power of Laser | 10%~100% continuously to be adjusted |
System Operation Environment | Windows XP/W7--32/64bits/W8--32/64bits |
Cooling Mode | Air cooling--Built-in |
Temperature of Operation Environment | 15℃~35℃ |
Power Input | 220V/50HZ/single phase or 110V/60HZ/single phase |
Power Requirement | <400W |
Communication Interface | USB |
Machine Dimension/after package | 920*830*1160mm |
Net Weight/gross weight | 120/170kg |
Optional | Rotary Device,Moving Table,other customized Automation |
Applicable Industry
1. Precision instruments, computer keyboards, auto parts, plumbing parts, communication equipment, medical equipment, bathroom equipment, hardware tools, luggage decoration, electronic parts, household appliances, clocks, molds, gaskets and stamps, data matrix.
2. Jewelry, mobile phone keyboards, buckles, kitchen utensils, knives, kitchen utensils, stainless steel products, aerospace equipment, integrated circuit chips, computer accessories, signage molds, elevator equipment, wires and cables, industrial bearings , building materials, hotel kitchens, military, plumbing.
3. Tobacco industry, biopharmaceutical industry, wine industry, food packaging, beverage, health products, plastic buttons, toiletries, business cards, clothing accessories, cosmetic packaging, car decoration, wood, logos, characters, serial numbers, barcodes, PET, ABS, plumbing, advertising, logo.
