Description
Enclosed Laser Marking Machines
Product Description
The enclosed laser marking machines has a wide range of applications, the mark is clear and beautiful, and will not disappear for a long time.
Product Parameters
Model series | Intelligent laser marking machine | |
Model | RL-20PI | |
Laser parameters | Laser source model | MAX 20W |
Output power | 18.5W | |
Beam quality M² | ≤1.4 | |
Pulse repetition frequency | 27-60 kHz | |
Laser wavelength | 1064±5 | |
Output power stability | <3% | |
Design life | About 100,000 working hours (non-service life) | |
Optical properties | Marking range | 100~150mm (range optional) |
Engraving depth | ≤1mm (depending on power and time) | |
Engraving speed | ≤10000mm/s | |
Repeat accuracy | ±0.002 | |
Mininum line width | 0. 1mm | |
Minimum character height | 0.15mm | |
Use environment | Cooling method | Built-in air cooling |
System power supply | 500W / 220V / 50Hz (110V can be connected) | |
Temperature, humidity | 0~40°, 30%≤RH≤85%, air conditioner should be installed when used outside the range | |
Oil mist, condensation | Not allowed | |
Other parameters | Operating system | Windows operating system |
File format | All fonts/types of WINDOWS operating system font library (standard USB input) | |
Dimensions | 50X30X60 mm | |
Total Weight | About 50kg | |
Product Application
Enclosed laser marking machines is especially suitable for marking of hardware tools, knives, kitchenware, plastic products, computer keyboards, metal jewelry, buttons, integrated circuits, packaging bottles, glasses frames, sanitary ware faucets and other products.
Product Packaging
1. Enclosed laser marking machines with standard wooden cases with sponge filled inside for packing protection.
2. The wooden case is fumigation free which is suitable by sea & by air.
3. Customized packing as per customer's requirement.
Certifications
FAQ
Q: How long is the shelf life of the machine?
A: The whole machine is guaranteed for one year.
Q: What are the requirements for the computer?
A: The smart machine is compatible with Windows® XP/7/8/10 32-bit and 64-bit operating systems. File transfers are performed via a USB connection to a computer at speeds up to 500 KB per second or direct transfer via a USB flash drive.
Q: Is there any maintenance for the laser machine?
A: All configurations of the enclosed laser marking machines are free maintenance.
Q: How does the mini machine work?
A: Laser machines work by directing a very powerful laser beam at precise focal lengths onto a variety of materials. Depending on the speed and power settings, the laser beam will either remove or cut through the surface of the material.
Q: What are the consumables?
A: If the enclosed laser marking machines is maintenance-free and has no consumables.
