Desktop Jewelry Laser Spot Welding

No need fill wire.
Fast welding speed.
Small heat effected zone.

Description

Product Description
Desktop jewelry laser spot welding is specifically for jewelry laser welding of a product, mainly used in gold and silver ornaments of the hole and spot welding blisters. It can realize spot welding, butt welding, seam welding and sealing welding.

Product Features
1. All accessories of the desktop jewelry laser spot welding using high technology integrated technology, stable and functional.
2. The energy, pulse width, frequency and light spot size can be adjusted in a large range to realize different welding effects.
3. Use the most advanced light shielding system to eliminate the irritation to eyes by light during working.
4. It is able to work 24 hours continuously, stable performance.
5. Human-based design accords with ergonomics, no fatigue after long time working.

Product Parameters

Model	RL-Y80
Laser output power	80W
Laser type	YAG pulse
Laser wavelength	1064um
Pulse width	0.1ms-20ms
Pulse energy	50J
Pulse frequency	0-50Hz
Size of welding spot	0.2mm-2.0mm
Adjusting range of light spot	1.8mm
Max. bearing of work bench	25KG
Repeating precision of work bench	-0.001
Positioning precision of work bench	-0.001
Sighting positioning system	HD-CCD monitor system
Cooling method	Water cooling
Max. output power	250W
Integrity power	5KW
Power supply	AC220VAC/380VAC+-15%/50HZ/25A
Guarantee	1 year

Product Application
Desktop jewelry laser spot welding widely used in jewelry ring soldering, precision watch repair, sand Hole repair, bracelet welding, necklace repair, glass frame welding, electric components welding etc.

spot welding sample3
