Laser Spot Welder For Jewelry
One-button operation.
Small heat affected zone.
Welding firmly.
Does not lead to the product deformation welding the weld depth is big.
Description
Laser Spot Welder For Jewelry
Product Features
1) Laser spot welder adopt imported ceramic concentrating cavity, high reflectivity, strong energy, high temperature resistance, corrosion resistance and long service life.
2) The whole machine is with ergonomic design, more suitable for the jewelry industry, the product is fine, beautiful, with stable performance, suitable for long-term continuous work needs.
3) LED ring type shadowless lamp, observe the workpiece without shadow, with high-definition parallel light path microscope, laser welding position observation is more clear.
4) High-magnification beam expansion system, to obtain a more precise spot, to meet the needs of fine laser spot welding.
Product Parameters
Model | Magic Box |
Laser Type | 1064nm YAG Laser |
Beam Diameter | 0.2-2.0mm |
Pulse Width | 0.1-10ms |
Frequency | 1.0~10.0Hz Continuously Adjustable |
Maximum Laser Pulse Energy | 40J |
Host Power Consumption | ≤1.5KW |
Cooling System | Convective air cooling |
Pump Source | Xenon lamp |
Aiming and Positioning | Microscope + HD digital CCD camera system |
Operating Mode | Touch Control |
Display Touch Screen | 10X high quality colorful Digital CCD |
Operating Language | English, Chinese |
Electrical Connection Values | AC220V ± 5%, 50HZ / 60HZ |
Machine Dimension | Ø295mm x H282mm |
Wooden Package Dimension | 40x45x48CM |
Machine Net Weight | 13.5KG |
Operating Environmental Temperature | ≤45℃ |
Humidity | < 90% non-condensing |
Application | Welding and repairing all kinds of jewelry and metal parts |
Product Details
Product Application
Laser spot welder widely used in various metal materials: gold, silver, platinum, copper, stainless steel and other metal materials.
Customer Feedback
Product Size & Packaging
Riselaser Service Features
1. High quality products with competitive price.
2. 7*24 Hours online After - sales service.
3. Delivery on time and excellent after-sales service.
4. Lifetime technical support for you.
5. Every laser spot welder will be tested before the delivery.
