300W Maxphotonics Single-Module CW Fiber Laser Source For Welding Cutting Cleaning
300W Maxphotonics Single-Module CW Fiber Laser Source Product introduction This 300W single-module continuous wave fiber laser is based on a modular design, with excellent beam quality, high stability, compact structure, air cooling, and continuous adjustment. The beam is transmitted through...
Description
300W Maxphotonics Single-Module CW Fiber Laser Source
Product introduction
This 300W single-module continuous wave fiber laser is based on a modular design, with excellent beam quality, high stability, compact structure, air cooling, and continuous adjustment. The beam is transmitted through optical fiber and QBH connector. It is very suitable for system integration with robots or machine tools, and is widely used for 3D printing, laser cutting, welding, etc.
Advantages
1.Up to 6KW output from CW single module series:
Better beam quality vs multi module lasers,greatly improved efficiency.
2.Excellent material processing performance.
High speed in thin sheet cutting.
Strong capability in thick material processing.
3.Compact design, maintenance free.
Highly integrated system with modular design.
Easy maintenance significantly reduce TCO.
4.Smaller size with higher stability,>60% reduction in volume.
Higher flexibility when integrated in to system.
5.High level vertical integration.
All key components are designed and produced in house
Strict quality control, high consistency and reliability
Application
Electronic communication industry.
Sheet metal processing.
Building materials derusting.
Jewelry restoration.
3C product processing.
As well as 3D printing.
Parameters
Model | MFSC-300W |
OPTICAL SPECIFICATIONS | |
Nominal Power 300W | Mode of Operation CW/Modulated |
Polarization | Random |
Power Tunability | 10 to 100% |
Wavelength | 1080 ± 10 nm |
Power Stability | ±1 % |
Laser Beam Quality | M² 1.1 to 1.2 |
Modulation Frequency | 20~50kHz |
Preview Red Light Power | 150μW |
FIBER DELIVERY SYSTEM | |
Interface | QCS/QBH(LOC) |
Length | 2m standard, other lengths optional |
Diameter | 20(25/30/50) μm |
Bending Radius | 200 mm |
ELECTRICAL RATINGS | |
Supply Voltage | 220VAC (-15% to +10%) Single-phase |
OTHER SPECIFICATIONS | |
Operating Temperature | 0 to +35℃ |
Storage Temperature | -10 to +60℃ |
Humidity | 10 to 90% |
Cooling Method | Air Cooling |
Dimension | 482×610.4×139.3 mm |
Weight | 26 kg |
Certificate
Exhibition
FAQ
Q1: Are you a factory or a trade company ?
A1: We are manufacturing laser machines and we provide perfect OEM and after-sale service.
Q2: How about the machine guarantee?
A2: We generally offer you 1 year guarantee.
Q3: How can I use the machine, if I'm a new buyer?
A3: We will deliver English manual and video with the machine to you. If you still need our help, please contact us.
Q4: How can I know your machine is designed for my product?
A4: You can send us samples and we test it on the machine.
